Price on request
Brand: Shimadzu
Origin: Japan
Model: AP225W
Capacity: 220gm
Readability: 0.01mg
Display Character: 0.00001gm
Repeatability: 0.01 mg for low loads ≤ 5g
Repeatability (Typical): 0.015mg for ≤ 20g, 0.03mg ≤ 100g, 0.05mg to weighing capacity
Minimum Weight: 20mg
Minimum Sample Weight (USP, 1% typical): USP 0.10% - 13mg, Lab 1%-2mg
Linearity: ±0.1mg
Response Time: 2 Seconds
Pan Size: 91 mm dia.
Body Dimensions: App. W212 X D411 X H345mm
Display: OEL display (dot matrix)
Unit: gm, lb., pc, ct, mg, Specific Gravity with 22 units
Housing: Aluminum Die Cast housing and static enclosure, Membrane type key
Interface: RS232C, USB
Leveling System: Manual Bubble Point Leveling with paddle
Security System: Menu Lock, Service Mode Lock,
Calibration: Motorized Automatic Internal & External with standard weight
Compliance: GLP, GMP & ISO 9000 Standards
21 CFR Part 11: Supported (Software is required for use.)
User ID & Password: 1 Admin and 60+ user id & password built in the balance, for unlimited user id & password you have to use software
Data Backup: Connect the balance via RS-232C (or RS-232 to USB adapter) to a Windows PC directly for Data Backup without software.
Print: Auto/manual single click print after stabilization
Over load: 150% over load protection
Operating temperature range: 5°C to 40°C
Power: 220V AC 50/60 Hz / 12 V DC
Weight: App. 7.9 kgs
Contact our team in Savar, Dhaka for AP-225W quotations, equipment selection and service support across Bangladesh.
